Motor coil winding data tools are a digital or manual system through which an electrician, technician or motor rewinder gets accurate data for coil winding of a motor.
These tools calculate or store technical values ​​such as motor’s SWG (Standard Wire Gauge), total turns, coil pitch, slots, HP, RPM and weight.

Find complete motor coil winding data with SWG, turns, coil pitch, and MFD info. Use digital tools to calculate and save time – 100% accurate results.

Types of Motor Coil Winding Data Tools

1. Manual Winding Charts
   These are paper-based tables that record every motor type.
2. Digital Winding Data Tools
   These are WordPress or desktop-based apps that:
3. This is a tool in which you get the exact winding data of a motor. For example:

• Enter the motor name (Crompton Greaves, V-guard, Etc.)
• Enter Slots Number (example 24,18, 36)
• Enter SWG number (example 22 SWG)
• Enter HP (example 0.5, 1hp,)
• Enter KW
• Enter MFD (Condenser) Example 10Mfd,100/120Mdf,36Mfd, Etc..
• Total turns
• Running coil vs. Starting coil
• Coil pitch
• Press the Search button
• And the tool immediately displays winding data

You just enter the name or details of the motor… and the tool gives you complete winding data. It works like a digital assistant for the technician.

Advantages — Benefits of Motor Coil Winding Data Tools

Time-saving — No need to manually calculate the data of every motor
Accuracy — Turns, SWG and total coils are obtained perfectly
Productivity Boost — Technician works with 100% confidence
Universal Reference — Database of multiple brand motors is available
Maintenance History — Record of when and how the winding was done

Wire Gauge Converter SWG to MM Best & No1 Conversion Tools

Software Tool for Fast and Optimized Stator Winding Design of Three-Phase Induction Motors 1

Manual Motor Coil Winding Machine No1 Best Deals in India

Who uses these tools?

• Motor rewinding technician
• industrial electrician
• Fan repair wale
• Trainer or student
• Blogger or YouTuber who shares knowledge

How to use Motor Coil Winding dataTools?

1. Open the tool (Web/App)
2. Enter motor name or HP
3. Click Search
4. You will find:

• Running/Starting SWG
• Turns
• Coil pitch
• MFD

5. Use data to directly apply to winding.

 Motor Coil Winding Data Tools Table (Example)

Motor Details (Winding Explanation):

Mini Water Motor (0.5 HP)

This motor is used in small domestic water pumps where light load and high efficiency is required.

27 SWG copper wire is used for running and 28 SWG for starting. Coil pitch is usually in the range of 1-6 to 1-12.

Crompton Motor (1 HP)

Heavy-duty pump motor in which speed is high (2880 RPM).

26×26 dual wire running coil gives more strength. Used for motor rewinding professionals.

Local Pump 45mm (0.5 HP)

Common pump, especially used in Indian rural areas.

This motor is affordable, but the winding detail is very important — wrong pitch can cause the motor to overheat.

1HP Centrifugal Pump

For Industrial and agricultural use.

For long life, selection of accurate MFD (Start + Run capacitor) is important.

Running winding has up to 22 SWG and short pitch 1-4, 1-8.
